Payload-Range
Loading Specification
Main Deck
Lower Deck
ULD Reference
Refer to above Main Deck
Cargo Freighter
Specifications
IL-62M Freighter
Payload-Range
Loading Specification
Main Deck
Lower Deck
ULD Reference
Refer to above Main Deck
| Payload (Tons) | 40,000 |
| Volume (cbm) | 230 |
| Main Door Dimension (LxH, cm) | 345x200 107x155 |
| Forward Door Dimension (LxH, cm) | 131x126 |
| After Door Dimension (LxH, cm) | 100x126 |
| Bulk Door Dimension (LxH, cm) | 70x76 |
| Max Range (km) | 6,500 |
| Cruise speed (km/h) | 820 |
| MTOW (kg) | 170,000 |
| MZFW (kg) | 84,000 |
| Crew & Cargo Attendants | 5 |
| Max fuel capacity (kg) | 86,000 |
| Average fuel burn (tons/h) | 7.0 |
| Minimum runway (m) | 3,150 |
